Main Description
SPECIFCATIONS
| CODE | LOAD | D | O | F | h | H | Features |
JM-MR105A | A15 | 900 | 790 | 1065 | 70 | 113 | Weight 64.4kg/20ft Full Load Qty 170 |
JM-MR105B | B125 | 900 | 790 | 1065 | 70 | 113 | Screw lock & Weight 74.8kg/20ft Full Load Qty 170 |
JM-MR105C | C250 | 900 | 790 | 1065 | 70 | 113 | Weight 74.8kg/20ft Full Load Qty 170 |
JM-MR105D | D400 | 900 | 790 | 1065 | 70 | 113 | Weight 96.2kg/20ft Full Load Qty 170 |
Product Details
JM-MR105A Composite Manhole Cover conforms to BS EN124 A15 Class and is suitable for areas which can only be used by pedestrians and pedal cyclists.
JM-MR105B Composite Manhole Cover conforms to BS EN124 D400 Class and is suitable for Carriageways of roads, hard shoulders and parking areas, for all types of vehicles.
JM-MR105C Composite Manhole Cover conforms to BS EN124 D400 Class and is suitable for gullytops installed in the area of curbside channels of roads.
JM-MR105D Composite Manhole Cover conforms to BS EN124 D400 Class and is suitable for Carriageways of roads, hard shoulders and parking areas, for all types of vehicles.
