Main Description
SPECIFCATIONS
| CODE | LOAD | D | O | F | h | H | Features |
JM-MS209C | C250 | 655x505 | 600x450 | 760x610 | 50 | 100 | 4 screw & Weight 47.0kg/20ft Full Load Qty 420 |
JM-MS209D | D400 | 655x505 | 600x450 | 760x610 | 50 | 100 | 4 screw & Weight 47.0kg/20ft Full Load Qty 420 |
 | BS EN124 A15 Class |  | BS EN 124 C250 Class |
| Suitable for areas which can only used by pedestrians and pedal cyclitst | Installed in the area of beside channels or road. | ||
 | BS EN124 B125 Class |  | BS EN124 D400 Class |
| Suitable for the footways, pedestrian areas and comparable areas, car parks or car parking decks. | For area of carriageways of roads, hard shoulders and parking areas, for all types of vehicles. |
FEATURES
 | Anti-UV |  | Surface pattern and other customization service is supported |
 | High loading capacity |  | Shock absorption by rubber sealing |
 | High anti-corrosion performance |
ACCESSORIES
 Anti-skid pattern |  Accessories |  Logo area |
 Lifting hole |  Screw lock |
